Jimi JC261 Dashcam AI 4G
4.6 19.00 views
La Jimi JC261 est une dashcam double camera 4G avec intelligence artificielle embarquee (ADAS + DMS). Successeur de la JC450, elle combine une camera route 1080P et une camera cabine 720P infrarouge dans un boitier compact. Video en direct via RTMP sur votre propre serveur, sans dependance cloud.
Ce qui la distingue
- Double camera : route (1080P, 85 degres) + cabine (720P, infrarouge, 56 degres)
- IA embarquee ADAS : alerte collision frontale (FCW), depart de voie (LDW), distance de securite (HMW)
- IA embarquee DMS : detection de fatigue, distraction, telephone au volant, tabagisme
- RTMP push : streaming video en direct vers votre propre serveur (commande RSERVICE)
- 4G LTE Cat.4 : variantes NA et Eurasie avec bandes separees
- 256 Go de stockage : 2 emplacements MicroSD (128 Go chacun, carte non incluse)
Fonctionnalites
- Video declenchee par evenement (freinage brusque, exces de vitesse, geofence, SOS)
- Streaming video en direct via 4G (RTMP)
- GPS integre pour localisation et historique des trajets
- Sortie relais pour coupure moteur
- WiFi 2.4 GHz (AP/STA/WiFi Direct) + Bluetooth BLE 4.0
- Capteur 3 axes integre
- Micro et haut-parleur integres
Ce qui est inclus
- 1 dashcam Jimi JC261 (camera route integree)
- Faisceau de cablage principal
- Kit de montage (adhesif 3M)
- Carte MicroSD non incluse (128 Go recommandee)
- Camera DMS JC171 vendue separement
- Installation par nos techniciens
- Network
- 4G LTE Cat.4
- Installation
- Hardwired
- Remote engine cut-off
- Yes
- AI
- ADAS (FCW, LDW, HMW) + DMS (fatigue, distraction, phone, smoking)
- REF
- JM-JC261
- SIM
- Nano SIM
- GNSS
- GPS
- WiFi
- 2.4 GHz (AP/STA/WiFi Direct)
- Brand
- Jimi IoT (Concox)
- Model
- JC261
- Weight
- 233g
- Network
- 4G LTE Cat.4
- Sensors
- 3-axis accelerometer, microphone, speaker
- Storage
- 2x MicroSD (TF), 128 GB each, 256 GB max total
- Protocol
- Concox (GT06)
- Bluetooth
- BLE 4.0
- Dimensions
- 109 x 69 x 52 mm
- Interfaces
- Micro USB, SOS, TTL, Relay
- Data points
- GPS, speed, heading, event-triggered video/photo, ADAS alerts, DMS alerts, relay status, SOS
- Front camera
- 1920x1080 / 25 FPS / F2.2 / 85 deg HFoV
- Power supply
- DC 9-30V
- Traccar port
- 5023
- Video format
- .ts
- Certifications
- FCC (2AMLF-JC261), CE, RoHS
- LTE bands (NA)
- FDD: B2/B4/B5/B12/B13/B14/B25/B26/B66, TDD: B41
- Video streaming
- RTMP push (RSERVICE command), JT/T 1078
- Optional cameras
- CI01 (720P/100 deg), CI03 (720P/119 deg), CE01 rear (720P/125 deg)
- DMS camera (JC171)
- 1280x720 / 100 deg HFoV / full color + monochrome auto-switch / IR-940 night vision / plug & play via JC261
- LTE bands (Eurasian)
- FDD: B1/B3/B5/B7/B8/B20/B28, TDD: B38/B40/B41
- Operating temperature
- -20°C to +65°C
