GV75W GPS tracker
Queclink

Queclink GV75W GPS Tracker · specs and details

Server address

gps.traxelio.com:5004
Queclink @Track Protocol (Traccar GL200 decoder, port 5004)

Send positions to this server

Check your GV75W

Enter the tracker IMEI first so Traxelio can confirm setup options before activation.

The Queclink GV75W is a sealed IP67 UMTS motorcycle GNSS tracker on gl200 (TCP port 5004) · 122 g, 1100 mAh backup, and 8–32 V set in Queclink Manage Tool or AT+GTBSI then AT+GTSRI SMS, then Traxelio shows live map, geofences, and confirmed immobilizer cut. It is not the 2G GV75.

IMEI

Check First

Hardware

Review

Protocol known IMEI check first Works with Queclink @Track Protocol (Traccar GL200 decoder, port 5004) protocol

Quick answers

Which protocol and port does the GV75W use on Traxelio?

Queclink @Track decoded as gl200 on TCP port 5004. Same ingest as GV75 and GV300. Do not pick gt06, h02, or Teltonika ports.

Is GV75W the same radio as GV75?

No. GV75W adds UMTS 850/1900/2100 (HSDPA) with GSM fallback. GV75 is 2G-only and about 100 g. This housing is 122 g, IP67, 1100 mAh, 8–32 V.

How do I provision GV75W?

Queclink Manage Tool over UART, or SMS AT+GTBSI then AT+GTSRI with report mode 3 (TCP). Traxelio does not publish a default PIN.

Is the case waterproof?

Ingress is IP67. Mount it on metal with the harness sealed. Manufacturer idle-current cut is a hardware mode — Traxelio does not publish a day-count from the 1100 mAh pack.

Overview

About the GV75W

The Queclink GV75W is the UMTS motorcycle-class sibling of the 2G GV75. Same IP67 102×46×20.5 mm housing class, 122 g instead of 100 g, Li-Polymer 1100 mAh, 8–32 V, RS232, and digital I/O. Radio is UMTS 850/1900/2100 plus GSM quad-band. Traxelio decodes @Track as gl200 on TCP port 5004. This page is not the 2G GV75. Point Queclink Manage Tool or AT+GTBSI then AT+GTSRI at gps.traxelio.com:5004, then Traxelio plots live map, geofences, and confirmed immobilizer cut after dashboard confirmation.

About Queclink

Looking for the Queclink configurator? Queclink supplies the tool. Use it to point a GV, GL or GMT tracker that sends @Track at gps.traxelio.com, port 5004.

Speaks the Queclink @Track Protocol (Traccar GL200 decoder, port 5004) protocol. Read the protocol reference →

Protocol known

Traxelio recognizes this protocol, then checks the exact IMEI and model details before activation.

Technical Specs

Device Specifications

Traxelio compatibility

Brand Queclink
Protocol Queclink @Track Protocol (Traccar GL200 decoder, port 5004)
Status Protocol known
Setup Signals IMEI check first
Setup Check hardware →

Hardware specifications

Network 3G, UMTS, 2G, GSM
GNSS GPS
Voltage range 8-32V
Battery 1100 mAh
IP rating IP67
Operating temperature -30 to +70 °C
Dimensions 102x46x20.5 mm
Weight 122 g
MPN GV75W

Accessories

12V/30A immobilizer relay (5-pin)

Open-drain DOUT wiring for engine cut

SKU: REL-5P-12V

Standard SIM with data + SMS

Provisioning and live reporting

SKU: SIM-DATA-SMS

Certified

Certifications

CE FCC

Downloads

GV75W · Also sold as Queclink GV75 family by other brands

Setup

Check Setup Options for Your GV75W

Setup guidance

Enter the tracker IMEI so Traxelio can review this exact hardware before setup.

Check hardware
See the Queclink setup guide →

Download or log in to Queclink Manage Tool

Windows UART tool for APN and server. SMS path is AT+GTBSI then AT+GTSRI.

Desktop download
Queclink GV500CG

Alternative model

Queclink GV500CG

This is not the same device, but it can be a practical alternative from the same brand.

F CFA 30,000

Common issues

Landed here expecting the 2G GV75

GV75 is the 2G sibling (about 100 g) on its own page. GV75W is UMTS + GSM in the same IP67 size. Port stays 5004 on both.

3G never attaches on a West African SIM

UMTS bands on this SKU are 850/1900/2100. Confirm the printed SKU before blaming Traxelio. GSM fallback still uses port 5004 once the radio attaches.

SMS AT+GTSRI error

AT+GTBSI with the SIM APN first. Password is the device password, not a four-digit SinoTrack PIN.

Queclink

Other Queclink Devices

Queclink

GV65

Verified

Queclink
Queclink

GB100

Queclink
Queclink

GB100MG

Queclink
Queclink

GL100

GL100
View All Queclink Devices

Alternatives

Comparable devices

Queclink

Queclink GV75

2G IP67 sibling · about 100 g, same gl200 port 5004

 Teltonika

Teltonika MTB100

2G motorcycle 1x5 on Codec 8 — IP54 splash, not IP67

 Queclink

Queclink GV300

Cabin 16-pin 2G sibling when the install is inside a dash

FAQ

Frequently Asked Questions

Common questions about using the GV75W with Traxelio

Traxelio can receive position reports from the GV75W over the Queclink protocol, and setup details are confirmed from the IMEI.

Start with the IMEI check on this page. Traxelio will confirm whether this exact hardware can send position reports and what setup it needs before activation.

This page lists the GV75W as a tracker model with a known protocol. Traxelio shows self-service setup only when full protocol support is available.

Check your GV75W before setup

Enter the tracker IMEI so Traxelio can review this exact hardware before activation.

Connect your tracker Add vehicle to your fleet
